| . | Tiger Explorer XR | Tiger Explorer XRX | Tiger Explorer XRT | Tiger Explorer XC | Tiger Explorer XCX | Tiger Explorer XCA |
| POWER | 139PS @ 9,300rpm | 139PS @ 9,300rpm | 139PS @ 9,300rpm | 139PS @ 9,300rpm | 139PS @ 9,300rpm | 139PS @ 9,300rpm |
| TORQUE | 123Nm @ 6,200rpm | 123Nm @ 6,200rpm | 123Nm @ 6,200rpm | 123Nm @ 6,200rpm | 123Nm @ 6,200rpm | 123Nm @ 6,200rpm |
| ENGINE TYPE | Liquid-cooled, in-line, 3 cylinder | Liquid-cooled, in-line, 3 cylinder | Liquid-cooled, in-line, 3 cylinder | Liquid-cooled, in-line, 3 cylinder | Liquid-cooled, in-line, 3 cylinder | Liquid-cooled, in-line, 3 cylinder |
| ENGINE SIZE | 1,215cc | 1,215cc | 1,215cc | 1,215cc | 1,215cc | 1,215cc |
| SEAT HEIGHT | 837/857mm | 837/857mm | 837/857mm | 837/857mm | 837/857mm | 837/857mm |
| (805 – 785 mm low seat version) | (805 – 785 mm low seat version) |
| FRONT SUSPENSION | 48mm, WP USD fork, adjustable rebound and compression damping | 48mm, WP USD fork, electrically adjustable in rebound and compression damping | 48mm, WP USD fork, electrically adjustable in rebound and compression damping | 48mm, WP USD fork, adjustable rebound and compression damping | 48mm, WP USD fork, electrically adjustable in rebound and compression damping | 48mm, WP USD fork, electrically adjustable in rebound and compression damping |
| REAR SUSPENSION | WP monoshock, adjustable in pre-load and rebound damping. Cast aluminium single sided swingarm | Semi-active WP monoshock with automatic preload adjustment. | Semi-active WP monoshock with automatic preload adjustment. | WP monoshock, adjustable in pre-load and rebound damping. Cast aluminium single sided swingarm | Semi-active WP monoshock with automatic preload adjustment. | Semi-active WP monoshock with automatic preload adjustment. |
| Cast aluminium single sided swingarm | Cast aluminium single sided swingarm | Cast aluminium single sided swingarm | Cast aluminium single sided swingarm |
| FRONT BRAKES | Dual 305mm discs, Brembo Monobloc 4-piston radial calipers | Dual 305mm discs, Brembo Monobloc 4-piston radial calipers | Dual 305mm discs, Brembo Monobloc 4-piston radial calipers | Dual 305mm discs, Brembo Monobloc 4-piston radial calipers | Dual 305mm discs, Brembo Monobloc 4-piston radial calipers | Dual 305mm discs, Brembo Monobloc 4-piston radial calipers |
| REAR BRAKES | Single 282mm disc, Nissin 2-piston sliding caliper | Single 282mm disc, Nissin 2-piston sliding caliper | Single 282mm disc, Nissin 2-piston sliding caliper | Single 282mm disc, Nissin 2-piston sliding caliper | Single 282mm disc, Nissin 2-piston sliding caliper | Single 282mm disc, Nissin 2-piston sliding caliper |
| TANK CAPACITY | 20L | 20L | 20L | 20L | 20L | 20L |
| DRY WEIGHT | 244kg | 246kg (244kg Low seat version) | 254kg | 246 kg | 253kg (251kg Low seat version) | 258kg |
| COLOURS | Jet Black | Jet Black | Crystal White | Jet Black | Jet Black | Crystal White |
| Crystal White | Crystal White | Lucerne Blue | Crystal White | Crystal White | Lucerne Blue |
| Phantom Black | Lucerne Blue | Cranberry Red | Phantom Black | Lucerne Blue | Matt Khaki Green |
| STANDARD EQUIPMENT | · ABS and Traction Control | Additional to the XR: | Additional to XRX: | · ABS and Traction Control | Additional to the XC: |
|
| · ‘Road’ and ‘Rain’ Riding Modes | · Cornering optimised ABS and Traction Control | · ‘Sport’ and ‘Rider’ adjustable Riding Modes | · ‘Road’ and ‘Rain’ Riding Modes | · Cornering optimised ABS and Traction Control |
|
| · Electrically adjustable screen | · ‘Off-road’ Riding Mode | · Hill Hold control | · Electrically adjustable screen | · ‘Off-road’ Riding Modes |
|
| · Centre stand | · Cruise Control | · Electrically adjustable Touring screen | · Centre stand | · Cruise Control |
|
| · Immobiliser | · Inertial Measurement Unit | · Tyre Pressure Monitoring System | · Immobiliser | · Inertial Measurement Unit |
|
| · 12V power socket | · Triumph Semi Active Suspension | · Pannier rails for aluminium panniers | · 12V power socket | · Triumph Semi Active Suspension |
|
| · USB power socket | · Self-cancelling LED Indicators | · Heated rider and passenger seat | · USB power socket | · Self-cancelling LED Indicators |
|
| · On-board computer | · Hand guards | Engine protection bars | · On-board computer | · Hand guards |
|
| Cast wheels | · Additional 12v power socket | · Sump guard | · Additional 12v power socket |
|
| · Heated grips | Spoke wheels for tubeless tyres | · Heated grips |
| Advanced on-board computer |
| · Advanced on-board computer |
|
| · Aluminium sump guard |
|
| · Stainless radiator guard |
