Srad Engine Case

2003RM125

27/10/2007 at 23:27

Hi guys I need to replace the case that is on the right hand side of engine if sitting on bike. The case that has the 2 silver bits on

i24.ebayimg.com/01/i/000/b9/9f/00bb_1.JPG

When i undo this case will U have to watch out for any cogs or anything falling out?

Cheers guys

Mac-Cecht

27/10/2007 at 23:35

Ones description is a tad vague. Are we talking about the cover on the bottom right???

"THINK" it's not illegal yet.

fastfitter

28/10/2007 at 07:11

Yes, sort of - the starter cluch is behind the upper cover ( # 20 ) which looks like it has to come off first......

so there's all this gubbins behind it ......

just tap the cases off gently and be prepared to catch any of the shims.

You'd be best to loosen off the two oilway plugs ( # 16 & 18 ) before undoing the cover retaining bolts
